– for massaging, salting, tumbling, marinating
– with cooling jacket for glycol water
– solid stainless steel construction with precision container
– diagonally welded baffles for 3D tumbling effect
for controlled, gentle turning, sliding, and
gliding movements
– programmable Siemens touch control in
separate stainless steel housing
– infinitely variable speed control
– suction device for brine and/or additives
– ejection baffle for fast, gentle
product discharge
– volume: 1500 liters
– container dim.: Diameter 1200 x L 1000 mm
– gearbox: 1.5 kW SEW
– voltage: 400 V, 50 Hz, 3 phases
– speed: infinitely variable
2-10 revolutions/minute
– vacuum pump: 1.1 kW Busch 0040
– water separator: 10 liters with drain valve
mounted on the right side of the machine hood
– control: Siemens KTP 700 / PLC S7; 34
programs on the switch arm
on the right side of the tumbler
– protection class: IP 66
– cover: 450 mm diameter with lake
suction device
– cleaning opening: 150 mm diameter
(additional opening optional)
– incl. complete cooler box, integrated
