fully electronic, continuous vacuum filling machine
for STRAIGHT-FILLING, PORTIONING and CIRCULATING
with removable linking gear ADG04
and FREY High-Line E- drive
filling capacity up to approx. 2,300 kg/hour
filling pressure approx. 40 bar
Machine housing and hopper
completely made of stainless steel
Filling hopper divisible 25/90 liters
Portioning range 5 – 100,000 g (5 – 999 g in 0.1 g steps)
Portioning speed max. 450 portions/min.
speed and portion pause length infinitely variable
Flow measurement, piece counter, piece count shut-off
Mass re-suction and portion addition 1st portion
memory for 200 filling programs,
electronic pulse control for clipping machines
digitally controlled vacuum system
vacuum pump 16 m³
industrial PC-control TC266
8,4 ” TFT color display (800 x 600)
touch operation, motion control
OPTIONAL:
Surcharge for DHG N-2 330 casing holder
for natural casings, including 3 filling tubes (12, 14, 20 mm)
each with a retaining ring, retaining star, lip, and sliding ring
-> € 3,800.00
